Premium Indoor LED Display Solution. The Crystal Series is a high-performance indoor LED display system designed for seamless, ultra-clear visual experiences in premium commercial spaces. Built with fine pixel pitch technology and high refresh rates, it delivers sharp resolution, vibrant colors, and smooth motion even at close viewing distances.
| Pixel pitch | P0.9 mm | P1.25 mm | P1.56 mm | P1.87 mm |
| LED Type | SMD 1010 Nationstar | SMD 1010 Nationstar | SMD 1212 Nationstar | SMD 1212 Nationstar |
| Cabinet size | W600mm x H 337.5mm | W600mm x H 337.5mm | W600mm x H 337.5mm | W600mm x H 337.5mm |
| Cabinet resolution | W-640 x H-360 | W-480 x H-270 | W384 x H216 | W320 x H180 |
| Size of module | W300 x H168.75 mm | W300 x H168.75 mm | W300 x H168.75 mm | W300 x H168.75 mm |
| Module Resolution | W320 x H180 | W240 x H135 | W192 x H108 | W160 x H90 |
| Pixel Density | 1137777 dots/msqr | 640000dots/msqr | 410914dots/msqr | 285968dots/msqr |
| Cabinet material | Die-casting | Die-casting | Die-casting | Die-casting |
| Driving IC | ICN / FM / DP | ICN / FM / DP | ICN / FM / DP | ICN / FM / DP |
| Refresh frequency | ≥1920-3840Hz | ≥1920-3840Hz | ≥1920-3840Hz | ≥1920-3840Hz |
| Brightness | 600cd/m2 | 600-800cd/m2 | 800-1000cd/m2 | 800-1000cd/m2 |
| Brightness Uniformity | ≥97% | ≥97% | ≥97% | ≥97% |
| Contrast Ratio | ≥5000:1 | ≥5000:1 | ≥5000:1 | ≥5000:1 |
| Max.power consumption | 680W/m² | 680W/m² | 680W/m² | 680W/m² |
| Ave.power consumption | 270W/m² | 270W/m² | 270W/m² | 270W/m² |
| Operating Voltage | DC4.5-5V | DC4.5-5V | DC4.5-5V | DC4.5-5V |
| Grey scale | 16Bits | 16Bits | 16Bits | 16Bits |
| Viewing angle(H/V) | 140ᴼ / 120ᴼ | 140ᴼ / 120ᴼ | 140ᴼ / 120ᴼ | 140ᴼ / 120ᴼ |
| IP grade | IP20 | IP20 | IP20 | IP20 |
