| Galaxy Series | Galaxy-Pro Series (Energy Saving) | |||
| Pixel Pitch | P4mm Full Colour | P6.6mm Full Colour | P4mm Full Colour | P6.6mm Full Colour |
| LED type | Full color 3 in 1 Bulb | 3 in 1 RGB Bulb | Full color 3 in 1 Bulb | 3 in 1 RGB Bulb |
| Lamp type | SMD1921 | SMD2727 | SMD1921 | SMD2727 |
| Light weight Aluminium Diecast Cabinet Size | W-960 x H-960 x D-75mm | W-960 x H-960 x D-75mm | W-960 x H-960 x D-75mm | W-960 x H-960 x D-75mm |
| Weight per cabinet | 25kg approx | 25kg approx | 25kg approx | 25kg approx |
| Cabinet Resolution | 240 x 240 dots | 144 x 144 dots | 240 x 240 dots | 144 x 144 dots |
| Module size | 320 x 160mm | 320 x 160mm | 320 x 160mm | 320 x 160mm |
| Module Resolution | 80 x 40dots | 48 x 24dots | 80 x 40dots | 48 x 24dots |
| Pixel Density | 62,500 dots/m² | 22,957 dots/m² | 62,500 dots/m² | 22,957 dots/m² |
| Refresh Rate | ≥3840Hz | ≥3840Hz | ≥3840Hz | ≥3840Hz |
| Frame Frequency | ≥60Hz | ≥60Hz | ≥60Hz | ≥60Hz |
| Scan Type | 1/8 Scan | 1/8 Scan | 1/8 Scan | 1/8 Scan |
| Brightness | ≥4500-5000cd/m² | ≥5000-5500cd/m² | ≥4500-5000cd/m² | ≥5000-5500cd/m² |
| Life span (At 50% Brightness) | 1,00,000 Hours | ≥100000 hours | 1,00,000 Hours | ≥100000 hours |
| MTBF | 10,000 hours | ≥10000 hours | 10,000 hours | ≥10000 hours |
| Protection | IP65 front / back | IP65 (for front/back) | IP65 front / back | IP65 (for front/back) |
| View Distance | >4-50 M | >6 -50 M | >4-50 M | >6 -50 M |
| Viewing Angle | 140ᴼ (H), 140ᴼ (W) | 140ᴼ (H), 140ᴼ (W) | ||
| Operation Temperature | 20ᴼC to 40ᴼC | 10ᴼC to 30ᴼC | ||
| Storage Temperature | 10ᴼC to 30ᴼC | 30ᴼC to 60ᴼC | ||
| Maximum Power Consumption | 540 W/m² | 540 W/m² | 400 W/m² | 400 W/m² |
| Average Power Consumption | 270 W/m² | 270 W/m² | 200 W/m² | 200 W/m² |
