| Pixel pitch | P2 mm | P2.5mm | P1.25 mm | P1.58 mm |
| LED Type | 3IN1 SMD 1921 | 3IN1 SMD 3535 | COB 1010 Nationstar / Topstar | COB 1010 Nationstar / Topstar |
| Cabinet size | 640 x 640mm / 640 x 480mm | 640 x 640mm / 640 x 480mm | 640 x 640mm / 640 x 480mm | W640mm x H480mm |
| Cabinet make | Mild steel | Mild steel | Aluminium Die-cast | Aluminium Die-cast |
| Module size | 320mm X 160mm | 320mm X 160mm | W320 x H160mm | W320 x H160mm |
| Module Resolution | 160 x 80 Dots | 128 x 64 dots | W300 x H168.75 mm | W202 x H101 Dots |
| Pixel Density | 2,50,000 pixels/㎡ | 1,60,000Pixels/m2 | 6,40,000 dots/msqr | 4,00,577 dots/msqr |
| Driving IC | MBI / ICN / SM | MBI / ICN / SM | ICN / FM / DP | ICN / FM / DP |
| Grey scale | 12-16Bit | 12-16Bit | 12-16Bit | 12-16Bit |
| Brightness | ≥5000cd/㎡ | ≥5500-6000cd/m² | ≥600-800cd/m2 | ≥600-800cd/m2 |
| Refresh frequency | ≥3840HZ | ≥3840HZ | ≥3840Hz | ≥3840Hz |
| Protection | IP65 front/ IP54 back | IP65 front/ IP54 back | IP.20 | IP.20 |
| Life span (At 50%Brightness) | 100000 Hours | 100000 Hours | 100000 Hours | 100000 Hours |
| View Distance | ≥4-5mtr | ≥7-8mtr | 2+mtr | 2+mtr |
| Viewing angle(H/V) | 120°(V) 140°(H) | 120°(V) 140°(H) | 140°(V) 120°(H) | 140°(V) 120°(H) |
| Operating Temperature | minus 20ᴼC to 50ᴼC | minus 20ᴼC to 50ᴼC | minus 20ᴼC to 50ᴼC | minus 20ᴼC to 50ᴼC |
| Operating Humidity | 10 %- 80% RH NoCondensation | 10 %- 80% RH NoCondensation | 10 %- 80% RH No Condensation | 10 %- 80% RH No Condensation |
| Storage Temperature | minus 20 ᴼC / 60 ᴼC | minus 20 ᴼC / 60 ᴼC | minus 20 ᴼC / 60 ᴼC | minus 20 ᴼC / 60 ᴼC |
| Operating Voltage | DC 4.5- 5V | DC 4.5- 5V | DC 4.5- 5V | DC 4.5- 5V |
