Crystal Series

f

Premium Indoor LED Display Solution

Key Features

The Crystal Series is a high-performance indoor LED display system designed for seamless, ultra-clear visual experiences in premium commercial spaces. Built with fine pixel pitch technology and high refresh rates, it delivers sharp resolution, vibrant colors, and smooth motion even at close viewing distances.

Key Features:

  • Ultra Thin Light weight Die-cast aluminium cabinet
  • Technically resilient with consistent stability
  • Energy-efficient with low power consumption

Applications:

Conference Room, Control Room, Broadcast & news studios, Metro Interiors

Enquire Now

Technical Specifications

Pixel pitch P0.9 mm P1.25 mm P1.56 mm P1.87 mm
LED Type SMD 1010 Nationstar SMD 1010 Nationstar SMD 1212 Nationstar SMD 1212 Nationstar
Cabinet size W600mm x H 337.5mm W600mm x H 337.5mm W600mm x H 337.5mm W600mm x H 337.5mm
Cabinet resolution W-640 x H-360 W-480 x H-270 W384 x H216 W320 x H180
Size of module W300 x H168.75 mm W300 x H168.75 mm W300 x H168.75 mm W300 x H168.75 mm
Module Resolution W320 x H180 W240 x H135 W192 x H108 W160 x H90
Pixel Density 1137777 dots/msqr 640000dots/msqr 410914dots/msqr 285968dots/msqr
Cabinet material Die-casting Die-casting Die-casting Die-casting
Driving IC ICN / FM / DP ICN / FM / DP ICN / FM / DP ICN / FM / DP
Refresh frequency ≥1920-3840Hz ≥1920-3840Hz ≥1920-3840Hz ≥1920-3840Hz
Brightness 600cd/m2 600-800cd/m2 800-1000cd/m2 800-1000cd/m2
Brightness Uniformity ≥97% ≥97% ≥97% ≥97%
Contrast Ratio ≥5000:1 ≥5000:1 ≥5000:1 ≥5000:1
Max.power consumption 680W/m² 680W/m² 680W/m² 680W/m²
Ave.power consumption 270W/m² 270W/m² 270W/m² 270W/m²
Operating Voltage DC4.5-5V DC4.5-5V DC4.5-5V DC4.5-5V
Grey scale 16Bits 16Bits 16Bits 16Bits
Viewing angle(H/V) 140ᴼ / 120ᴼ 140ᴼ / 120ᴼ 140ᴼ / 120ᴼ 140ᴼ / 120ᴼ
IP grade IP20 IP20 IP20 IP20
