Lumina Series

f

High Definition Indoor LED Display

Key Features

The Lumina Series is a high definition indoor LED display engineered for premium commercial environments that demand exceptional image clarity and reliability. Featuring fine pixel pitch options and advanced LED technology, it delivers sharp visuals, rich colors, and smooth performance for close viewing applications.

Key Features:

  • Seamless Crystal Series
  • Sleek, premium look that enhances interior aesthetics
  • Alluminium Die-cast/ MS cabinet

Applications:

Corporate Office, Mall, Bank, Hotel Lobbies

Technical Specifications

Pixel pitch P2 mm P2.5mm P1.25
mm
P1.58
mm
LED Type 3IN1 SMD 1921 3IN1 SMD 3535 COB 1010 Nationstar / Topstar COB 1010 Nationstar / Topstar
Cabinet size 640 x 640mm / 640 x 480mm 640 x 640mm / 640 x 480mm 640 x 640mm / 640 x 480mm W640mm x H480mm
Cabinet make Mild steel Mild steel Aluminium Die-cast Aluminium Die-cast
Module size 320mm X 160mm 320mm X 160mm W320 x H160mm W320 x H160mm
Module Resolution 160 x 80 Dots 128 x 64 dots W300 x H168.75 mm W202 x H101 Dots
Pixel Density 2,50,000 pixels/㎡ 1,60,000Pixels/m2 6,40,000 dots/msqr 4,00,577 dots/msqr
Driving IC MBI / ICN / SM MBI / ICN / SM ICN / FM / DP ICN / FM / DP
Grey scale 12-16Bit 12-16Bit 12-16Bit 12-16Bit
Brightness ≥5000cd/㎡ ≥5500-6000cd/m² ≥600-800cd/m2 ≥600-800cd/m2
Refresh frequency ≥3840HZ ≥3840HZ ≥3840Hz ≥3840Hz
Protection IP65 front/ IP54 back IP65 front/ IP54 back IP.20 IP.20
Life span (At 50%Brightness) 100000 Hours 100000 Hours 100000 Hours 100000 Hours
View Distance ≥4-5mtr ≥7-8mtr 2+mtr 2+mtr
Viewing angle(H/V) 120°(V) 140°(H) 120°(V) 140°(H) 140°(V) 120°(H) 140°(V) 120°(H)
Operating Temperature minus 20ᴼC to 50ᴼC minus 20ᴼC to 50ᴼC minus 20ᴼC to 50ᴼC minus 20ᴼC to 50ᴼC
Operating Humidity 10 %- 80% RH NoCondensation 10 %- 80% RH NoCondensation 10 %- 80% RH No Condensation 10 %- 80% RH No Condensation
Storage Temperature minus 20 ᴼC / 60 ᴼC minus 20 ᴼC / 60 ᴼC minus 20 ᴼC / 60 ᴼC minus 20 ᴼC / 60 ᴼC
Operating Voltage DC 4.5- 5V DC 4.5- 5V DC 4.5- 5V DC 4.5- 5V
